DGT1S - DIN Rail Load Cell Amplifier

Dini Argeo

Availability: In stock

£0.00

Quick Overview

Compact, multifunction weight transmitter / indicator, for panel mounting on DIN bar.

It allows the direct reading and diagnostics of the connected weighing system. The wide range of available interfaces, makes it easy to integrate the weighing with any automation system. CE-M approved (OIML R-76 / EN 45501). MID approved (OIML R-61).

* Required Fields

£0.00

Add to Cart

Mains Features:
• Easy to use 5-key waterproof keyboard.
• Red LED display with 6 8-mm digits and 6 LEDs for showing active functions.
• Standard dimensions for mounting on DIN bar.
• Calibration, Set-Up parameters, configurable from keyboard or from PC with DINI TOOLS.
• Up to 10.000e or multirange 2 x 3000e @ 0,3 µV/d in CE-M approved version for legal for trade use.
• Up to 1.000.000 displayable divisions with internal resolution up to 3.000.000 points.
• Up to 8 signal linearization points with DINITOOLS (3 from keypad).
• 1 channel A/D 24-bit sigma-delta conversion, up to 3200 conv./sec. autoselect.
• Connectable with up to 8 analogue load cells with 350 Ohm input resistance.
• From 12 Vdc to 24 Vdc power supply.

Communication 4 - 20ma / 0 - 10v
ATEX Zone No
Display No
Power Requirements 12-24vdc
IP Rating No Rating
Manufacturer Dini Argeo
