SPD Series Single Point Load Cells
Load cells for off centre loads, suitable for building CE-M approved scales with a single load cell with maximum dimensions of 350x350mm.
Starting at £80.00 £96.00
- C3 precision class
- Off center load compensated
- Aluminium alloy construction
- IP66 protection
- Max. capacities from 3 to 75 kg
- For platforms with dimensions up to 300 x 300 mm
- Shielded connection cable
- OIML and test certificates available upon request
- Ideal for applications up to 100,000 divisions (in combination with Dini Argeo “X-CORE” electronics)
- Sensitivity: 2 ±0.2 mV/V
- Zero balancing: ±0.1 mV/V
- Maximum size of the weighing area: 350 x 350 mm
- Thermal compensation: -10°C/+40°C
- Working temperature range: -30°C/+70°C
- Maximum tolerated power voltage: 15 Vdc
- Input resistance: 406 ±15 Ohm
- Output resistance: 350 ±3 Ohm
- Insulation resistance: >2000 MOhm
- Maximum static load: 150% F.S.
- Breaking load: 300% F.S.
- 4-pole shielded cable, length 3 m, diameter 3.8 mm with black PVC sheath
| Cable Length | 3m |
|---|---|
| IP Rating | IP66 |
